Image is representational - see mfr. specs

Switch Snap Action N.O./N.C. SPDT Straight Lever Wire Lead 10.1A 250VAC 186.42VA 0.66N Screw Mount

+ see all

Технический паспорт АКСЕССУАРЫ Notify Me

RoHS Compliant
Box Упаковка
Certificate of Compliance Guarantee
Описание +
Switch Snap Action N.O./N.C. SPDT Straight Lever Wire Lead 10.1A 250VAC 186.42VA 0.66N Screw Mount
Product Highlights:
  • Moisture resistant
  • 3 contact arrangements
  • Long life coil spring mechanism
  • Choice of button or hinged actuator
  • 10-inch, 16 gauge leads attached
  • Custom wire and harness designs available upon request
Search Keywords: E7240HT
спецификация +
  • Product Attribute
    Attribute Value Select Attribute
  • поставщик:
    ZF Electronic Systems
  • Артикул / №:
    E72-40HT
  • Единица измерения:
    Per Each
  • RoHS:
    Yes
  • HTS:
    8536509040
  • COO:
    MX
  • ECCN:
    EAR99
  • Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
    200
  • Mounting:
    Through Hole
  • Pole Throw Configuration:
    SPDT
  • Switch Configuration:
    N.O./N.C.
  • Actuator Material/Style:
    Stainless Steel/High Temperature Thermoplastic Nylon/Lever
  • Contact Rating @ Voltage:
    186.42@UL A
  • Maximum Movement Differential:
    0.61 mm
  • Operating Force:
    0.66 N
  • Termination Style:
    Wire Lead
  • Dimension:
    40.46 x 9.78 mm
  • Body Orientation:
    Straight
  • IP Rating:
    N/A
Tools/3D Models +
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
Backordered, But More coming soon
Минимальный заказ:
5
20 Weeks Можно отправить 4.11.25
Отложенный заказ
КОЛ-ВО
Unit Price
5
$27.71
25
$23.76
50
$21.81
200
$21.58
400
$21.37
600
$21.15
1 000 +
$20.94
Click for Quote
Авторизоваться чтобы разблокировать специальные цены
