CP1-12V by panasonic electronic components
Image is representational - see mfr. specs

CP1-12V

Panasonic Electronic Components

Relays 12VDC 225Ohm 20(NO)/10(NC)A SPDT(14mm 13mm 9.5mm) THT Automotive Relay Automotive

+ see all

データシート アクセサリー Notify Me

RoHS遵守
BOX 包装
Certificate of Compliance Guarantee
説明 +
Relays 12VDC 225Ohm 20(NO)/10(NC)A SPDT(14mm 13mm 9.5mm) THT Automotive Relay Automotive
Search Keywords: CP112V
仕様 +
  • Product Attribute
    Attribute Value Select Attribute
  • サプライヤー:
    Panasonic Electronic Components
  • 部品番号:
    CP1-12V
  • 測定単位:
    Per Each
  • RoHS:
    Yes
  • HTS:
    8536410020
  • ECCN:
    EAR99
  • サプライヤー標準パック This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
    40
  • Contact Form:
    SPDT (1 Form C)
  • Relay Construction:
    Non-Latching
  • Max Contact Current:
    20A (NO) / 10A (NC)
  • Coil Voltage:
    12 VDC
  • Coil Current:
    53.3 mA
  • Coil Resistance:
    225 Ohm
  • Contact Material:
    Silver(Cadmium Free)
  • Must Operate Voltage:
    7.2 VDC
  • Must Release Voltage:
    1 VDC
  • Operate Time:
    10 ms
  • Seal:
    Sealed
  • Mounting:
    Through Hole
  • Termination Style:
    PC Pin
  • Dimension:
    14 x 13 x 9.5 mm
  • Operating Temperature:
    -40 to 85 °C
  • Packaging:
    Tube
Tools/3D Models +
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
在庫: 7,588
Ships today, if you order in
最小注文:
40
複数:
40
24 Weeks 出荷できます 5/6/25
45ドルフラットレート配送:
カートに追加
数量
Unit Price
40
$2.02
120
$1.95
280
$1.83
520
$1.65
1,000
$1.60
2,520
$1.56
5,000
$1.54
7,520 +
$1.51
Suppliers Standard Package
