2-647125-4 by te connectivity / amp brand
Image is representational - see mfr. specs

2-647125-4

TE Connectivity / AMP Brand

04P MTA156 SHRD HDR ASSY LF

+ see all

Datasheet Accessories Notify Me

RoHS Compliant
Bag Packaging
Certificate of Compliance Guarantee
Description +
04P MTA156 SHRD HDR ASSY LF
Search Keywords: 26471254
SPECS +
  • Product Attribute
    Attribute Value Select Attribute
  • Supplier:
    TE Connectivity / AMP Brand
  • Part No:
    2-647125-4
  • Unit of Measure:
    Per Each
  • RoHS:
    Yes
  • HTS:
    8536694040
  • COO:
    CN
  • ECCN:
    EAR99
  • Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
    500
  • Mating Retention Type:
    Latch Detent
  • Number of Positions:
    4
  • Contact Retention Within Housing:
    Without
  • Circuit Application:
    Power
  • Housing Material:
    Polyester - GF
  • Packaging Quantity:
    500
  • Right Angle Bending Side:
    Front
  • Connector & Contact Terminates To:
    Printed Circuit Board
  • Connector Mounting Type:
    Board Mount
  • Termination Method to Printed Circuit Board:
    Through Hole - Solder
  • Glow Wire Rating:
    Standard Part - Not Glow Wire
  • Mating Retention:
    With
  • Number of Rows:
    1
  • PCB Mount Orientation:
    Right Angle
  • Contact Mating Area Plating Material:
    Tin
  • Rectangular Power Connector Type:
    Header
  • Panel Mount Feature:
    Without
  • Number of Power Positions:
    4
  • Contact Mating Area Plating Material Finish:
    Matte
  • Mating Alignment:
    With
  • Contact Base Material:
    Copper Alloy
  • PCB Mount Alignment:
    Without
  • UL Flammability Rating:
    UL 94V-0
  • PCB Mount Retention:
    Without
  • Sealable:
    No
  • Connector Profile:
    Standard
  • Contact Current Rating (Max):
    7 A
  • Strain Relief:
    Without
  • Mating Alignment Type:
    Polarization
  • Connector & Housing Type:
    Plug
  • Contact Underplating Material:
    Nickel
  • Contact Layout:
    Inline
  • PCB Contact Termination Area Plating Material:
    Tin
  • Connector System:
    Wire-to-Board
  • UL Rating:
    Recognized
  • Housing Color:
    Black
  • Operating Voltage:
    600 VAC
  • Contact Type:
    Pin
  • Header Type:
    Fully Shrouded
  • Agency/Standard:
    CSA , UL
  • Contact Mating Area Plating Material Thickness:
    3.81 – 8.89 µin, 150 – 350 µm
  • Centerline (Pitch):
    .156 in, 3.96 mm
  • PCB Thickness (Recommended):
    .062 in, 1.57 mm
  • Termination Post & Tail Length:
    .118 in, 3 mm
  • Operating Temperature Range:
    -55 – 105 °C, -67 – 221 °F
  • Mating Post Length:
    .3 in, 7.62 mm
  • Packaging Method:
    Box & Carton
  • Connector Height:
    .525 in, 13.34 mm
  • CSA Rating:
    Certified , LR 7189
  • Product Length:
    .718 in, 18.24 mm
  • PCB Contact Termination Area Plating Material Thickness:
    39.37 µin, 1 µm
  • Approved Standards:
    UL E28476
  • Contact Underplating Material Thickness:
    50 µin, 1.27 µm
Tools/3D Models +
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
In Stock: 7
Ships today, if you order in You may purchase in-stock quantity up to 7
MOQ for In Stock Qty:
10
Available in less than min:
7
MOQ for out of Stock Qty:
750
17 Weeks can ship 3/20/25
ADD TO CART
Qty
Unit Price
1
$3.993
10
$3.630
250
$2.340
500
$2.270
750
$2.200
1,500
$2.170
2,250
$2.140
3,000 +
$2.100
Suppliers Standard Package
Click for Quote
Log in to unlock special pricing
Item may be subject to tariff fee if shipping within the United States
