152892

TE Connectivity / AMP Brand

SIZE 20 PIDG R/T NO.10 NYLON

Datasheet Accessories Notify Me

RoHS Compliant

Box Packaging

Certificate of Compliance Guarantee

Description +

SIZE 20 PIDG R/T NO.10 NYLON

Product Highlights:

Terminal Shape = Ring Tongue
Receptacle Style = Straight
Body Style = PIDG
Barrel Type = Closed Barrel
Wire/Cable Type = Regular Wire

Search Keywords: 152892

SPECS +

Product Attribute

Attribute Value Select Attribute
Products found: 0 Show Similar
Supplier:

TE Connectivity / AMP Brand
Part No:

152892
Unit of Measure:

Per Each
RoHS:

Yes
HTS:

8536904000
COO:

US
ECCN:

EAR99
Supplier Standard Pack

1000
Type:

Ring Tongue Terminal
Gender:

N/A
Tab Size:

N/A
Stud Size:

5 mm
Wire Size:

20 AWG
Color:

Purple/Red
Operating Temperature:

105(Max) °C

Tools/3D Models +

3D PDF

EE ToolBox

Product Guides +

Product Drawing - RING TONGUE, PIDG

Datasheet

Product Specification - Pre-Insulated Diamond Grip (PIDG) Terminals, Splices, and End Caps

This product is discontinued, but still in stock.
This product is NOT RoHS Compliant. See alternative
Different product options available. See alternative
Different packaging options available. See alternative
Possible Replacement options available. See alternative
Item discontinued
End of Life: Final orders must be placed by
Item discontinued

In Stock: 1

Can Ship immediately You may purchase in-stock quantity up to 1

MOQ for In Stock Qty:

Available in less than min:

MOQ for out of Stock Qty:

2500

Factory Lead-Time:

26 Weeks can ship 5/9/25

Qty

Unit Price

$3.817

$3.470

500

$3.410

1,000

$3.360

2,500

$3.310

5,000

$1.750

7,500

$1.200

10,000 +

$1.180

Suppliers Standard Package

Accessories

576779

HHHT PIDG PEEK STRATO 20 ASSY

1901611-1

CERTI-Crimp Hand Tool Assembly
