CB1-P-12V by panasonic electronic components
Image is representational - see mfr. specs

CB1-P-12V

Panasonic Electronic Components

Power Relay 12VDC 40A SPDT(26x22x26)mm THT Automotive

+ see all

Datasheet Accessories Notify Me

RoHS Compliant
BOX Packaging
Certificate of Compliance Guarantee
Description +
Power Relay 12VDC 40A SPDT(26x22x26)mm THT Automotive
Search Keywords: CB1P12V
SPECS +
  • Product Attribute
    Attribute Value Select Attribute
  • Supplier:
    Panasonic Electronic Components
  • Part No:
    CB1-P-12V
  • Unit of Measure:
    Per Each
  • RoHS:
    Yes
  • HTS:
    8536410050
  • COO:
    JP
  • ECCN:
    EAR99
  • Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
    50
  • Contact Form:
    SPDT (1 Form C)
  • Relay Construction:
    Non-Latching
  • Max Contact Current:
    40A (NO) / 30A (NC)
  • Coil Voltage:
    12 VDC
  • Coil Current:
    117 mA
  • Coil Resistance:
    103 Ohm
  • Contact Material:
    Silver(Cadmium Free)
  • Must Operate Voltage:
    7 VDC
  • Must Release Voltage:
    4.2 VDC
  • Operate Time:
    15 ms
  • Seal:
    Sealed
  • Mounting:
    Through Hole
  • Termination Style:
    PC Pin
  • Dimension:
    26 x 22 x 26 mm
  • Operating Temperature:
    -40 to 85 °C
  • Packaging:
    Carton
Tools/3D Models +
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
In Stock: 622
Ships today, if you order in
On Order:
3,000   can ship 12/4/24
Minimum Order:
50
Order Increment:
50
24 Weeks can ship 5/8/25
ADD TO CART
Qty
Unit Price
50
$3.92
100
$3.76
250
$3.33
500
$3.03
1,000
$2.85
2,500
$2.81
5,000
$2.76
7,500 +
$2.72
Suppliers Standard Package
Click for Quote
Log in to unlock special pricing
